post #1 of 14 (permalink) Old 12-03-2010, 06:46 PM Thread Starter
Member

Join Date: Dec 2010
Posts: 7
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Talking Finally Installed a Heated Steering Wheel In My 2008 LR3 HSE!

I finally did it! I successfully modified and installed a heated steering wheel into my 2008 LR3 HSE! This project took several weeks to do in total. Had to wait for several needed parts to arrive from Roverparts (eBay). By no means was this a cheap modification. But it was a lot of fun to do and is so worth it in my opinion.

I love my LR3 and since buying it in 2008, my only gripe about it was that it didn't come with a heated wheel. I always felt that adding a heated wheel would be simple. After all, the 2009 RRS came with it as an option and the wheel is identical to my LR3.

In addition to the heated steering wheel, I found out that I needed several more parts to make the heating wheel function to work such as the switch, clockspring, ECU and wire harnesses and connectors (which came with the ECU and steering wheel).

I also was able to get some instructional feedback from Disco3.co.uk under the LR4, in-car electronics section. I am thankful to several posters on that site who helped guide me throughout this ordeal.

Since I am only allowed 4 pictures to post here, I included a link to my photobucket album where I have more pics of this modification.

Image hosting, free photo sharing & video sharing at Photobucket

My hands are now TOASTY, TOASTY, TOASTY!

Some pics below:

New clockspring (Note the 12 volt connector for the heated wheel at the 12 o'clock position)

[IMG][/IMG]

12 volt source connected into the side port of the new clockspring

[IMG][/IMG]

Heated wheel ECU which controls heating for the wheel

[IMG][/IMG]

All warm and toasty! NOTE the illuminated "on" indicator on the switch

[IMG][/IMG]

Cheers,

Vinny
vinnysca is offline
Sponsored Links
Advertisement

post #2 of 14 (permalink) Old 12-06-2010, 07:02 AM
Senior Member

Join Date: Mar 2010
Location: Great White North against the Rocks
Posts: 122
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Good work. I took the lazy route.....I wear gloves.
ktm_525 is offline
post #3 of 14 (permalink) Old 12-06-2010, 07:25 AM
Super Trooper

cnfowler's Avatar

Join Date: Jul 2010
Location: Denver Metro
Posts: 1,176
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 14 Post(s)
Garage
Very nice. Man I wish my Rangie had a heated steering wheel. I wonder why more vehicles these days don't offer it as an option. Heck, most cars now can be had with heated glass, heated mirrors, and heated seats. So what's the deal with heated steering wheels? If offered, that would be an option I'd spring for everytime. My hands get cold very easily. Living in the 2nd coldest town in Colorado, a heated steering wheel would be awesome.

Colin
cnfowler is offline

post #4 of 14 (permalink) Old 12-22-2010, 05:22 PM
Member

Join Date: Dec 2010
Location: Ontario Canada
Posts: 2
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
heated wheel

Thats great!that doesnt look like a cheap job at all???out of curiosity?$$$?
up here in the great white north it gets pretty frosty.
cheers
O-live is offline
post #5 of 14 (permalink) Old 12-23-2010, 08:50 AM Thread Starter
Member

Join Date: Dec 2010
Posts: 7
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Quote:
Originally Posted by O-live View Post
Thats great!that doesnt look like a cheap job at all???out of curiosity?$$$?
up here in the great white north it gets pretty frosty.
cheers
No. Not cheap at all (compared to the $100 option when one customizes an LR4 with a heated wheel).

Just to give you a rough estimate, the clockspring alone was $400. PLUS, you need to buy 2 separate heated wheels (the 2009 RRS heated wheel didn't come with an ECU for the wheel), but the 2010 LR4 wheel did. And each wheel were both over $500 at least.

So yea, it wasn't cheap. But, well worth the mod in my opinion.

Vince
vinnysca is offline
post #6 of 14 (permalink) Old 12-24-2011, 04:27 AM
Member

Join Date: Jan 2011
Posts: 1
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
You Photobucket link doesn't work, try to post again
gruodiz is offline
post #7 of 14 (permalink) Old 01-02-2012, 11:22 AM
Member

Join Date: Dec 2004
Location: La Grande, Oregon USA
Posts: 33
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
My '07 RR L322 had a heated steering wheel, but it got so hot I never used the heat feature. I hope yours is better.

'08 Land Rover LR3
'86 Ninety V8 Station wagon
'89 Classic Mini


Gone but not forgotten:
'07 Range Rover HSE, '89 Targa, '96 Land Rover Discovery SD, '00 Range Rover HSE, '07 FJ Cruiser, '04 Land Rover Discovery SE7, '96 Porsche 911 Carrera 4 Coupe,'04 Mini Cooper S, '11 Mini Cooper Countryman All4, '83 Porsche 911
Paul K is offline
post #8 of 14 (permalink) Old 12-16-2014, 05:00 AM
Member

Join Date: Dec 2014
Posts: 1
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Hi new here. I know this thread is probably dead. But I'm interested in doing to retro fit for the heated steering wheel.

Some questions:

Why did you need to steerin wheels? And which one did you end up using ? The RRS wheel or the LR4 wheel.

And the clock spring: was it from a RR or LR4? I found a heated one and wanted to know if it would work. It's from a RR.

I can and probably will PM you since this thread is 4 years old now.

Any info will help Thanks.
RoverLr3 is offline
post #9 of 14 (permalink) Old 12-24-2014, 08:32 AM
Member

Join Date: Sep 2012
Posts: 26
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
That's dedication, heated steering wheels are amazing...
degen is offline
post #10 of 14 (permalink) Old 12-24-2014, 09:44 AM
member

SafariDave's Avatar

Join Date: Feb 2008
Location: Brooklyn, NY
Posts: 1,739
Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 131 Post(s)
I wish I had one. Super Awesome! Great job!!!
Dave

The City is a Jungle.
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.


Present Land Rovers
1999 LR Disco II SD7 White 150K miles 'The Beach Boy' (PR truck)
2005 LR3/ D3 SE 4.4 Bonatti 'Fancy Professor' (my girl's LA LR3)
2005 LR3/ D3 SE 4.4 Bonatti 'The Rhino'
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
(my NYC LR3)
De-tangoed Headlights, LR4 Style Grille, Dueler Alenza HL 255/55/19

Past Land Rovers
1999 LR Disco II SD Niagara Grey 'Old Rhino' 200K+ miles (Sold)
1991 Range Rover Classic Green 'The Turtle' 200K+ miles (Sold)
1988 Range Rover Classic White 'The Rust Bucket' (Sold)
SafariDave is offline
post #11 of 14 (permalink) Old 12-24-2014, 11:41 PM
disco biscuit

disco biscuit's Avatar

Join Date: Nov 2010
Location: South East Texas
Posts: 1,054
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
I wish somebody already converted any steering wheel to the disco 2... With its crappy horns, wrap worn way before I owned it. This thread is ancient. Somebody shoulda done all the hard work for me by now....

Sent from AutoGuide.com Free App
disco biscuit is offline
post #12 of 14 (permalink) Old 07-10-2015, 09:56 AM
Member

Join Date: Jan 2014
Posts: 13
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Sorry to dredge up this thread but really need to know where I can get this two pronged connector so I can get power to my heated steering wheel.
Attached Thumbnails
Click image for larger version

Name:	power supply to heated wheel.JPG
Views:	1243
Size:	69.0 KB
ID:	58306
brjp1 is offline
post #13 of 14 (permalink) Old 07-15-2015, 06:53 AM
Member

Join Date: Dec 2012
Location: Lagrange, OH
Posts: 12
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Lol That's pretty funny I just start the car and let it sit for a little bit to warm before I go off on any adventures. My chevy has remote start i use that all the time in the winter.. It's supposed to turn on my heated seats but never seems to
dpedraza is offline
post #14 of 14 (permalink) Old 02-11-2019, 07:08 AM
Member

Join Date: Apr 2013
Posts: 1
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
I am reviving this thread in hopes of converting my 2009 LR3. I have the opportunity to get a heated wheel with clock spring off of a 2012 LR4. Is there anything else that I would need for this conversion or would this be it?


Thank you,


Rob
crtfour is offline
